1.2 Megawatt Ultra-Fast Charging System

1.2MW Ultra-Fast Charging | Liquid-Cooled | SiC Based

Overview

The Ohmitron MCS-1000 is a next-generation megawatt charging solution built for large-scale electric mobility. Designed using SiC technology, it delivers 1.2MW DC with liquid-cooled connectors and modular converters, charging 850kWh EV batteries under 20 minutes.

Charging Standard: MCS, ISO 15118-20 Compliant
Power Delivery: Up to 1000 kW DC
Cooling: Hybrid Liquid-to-Air with Chiller
Display: 10” Touchscreen + LED Indicators
Communication: ISO 15118 / CAN / Ethernet

Environmental & Protection

Cooling: Liquid-Cooled System
Operating Temp: -33°C to +85°C
Humidity: 0–97% RH, non-condensing
Altitude: Up to 4000 m (derating above 2000 m)
Noise Level: < 70 dBA @1m
Protection: OVP / UVP / OCP / Reverse DC / Isolation Detection

Communication & Compliance

Protocols: OCPP 2.0.1, ISO 15118-20, Modbus TCP/IP, RS485
Remote Monitoring: Firmware Updates, Diagnostics, Load Mgmt
Plug & Charge Support (ISO 15118)
Certifications: IEC 61851-1, IEC 61851-23, ISO 15118
ADA Compliant

Input / Output Specs

Parameter	Specification
Input Voltage	3Φ 4.16 kV AC ±15%
Input Current	Max 200 A
Max Input Power	1050 kVA
Output Voltage	200 – 1500 V DC
Output Current	Up to 1500 A
Power Conversion Efficiency	>97%
Power Factor	>0.99
THD	< 3%

Mechanical Specifications

Parameter	Value
Charging Pile Size (H×W×D)	2100 × 700 × 500 mm
Power Cabinet Block Size	2200 × 1000 × 800 mm (×2)
Material	Powder-Coated Aluminum or Steel
Mounting	Floor-standing with bolted baseplate
Weight	~1200 kg (Total Power Cabinet)
Ingress Protection	IP65
Cooling Type	Liquid + Air Hybrid
